View More >>As a Car Engine Timing Chain Tensioner Manufacturers, we match product configuration to the application, operating limits, interfaces and acceptance criteria defined for each project.
Huzhou Nanxun Jingtong Auto Parts Manufacturing Co., Ltd. is a China-based manufacturer of automotive engine timing chain system components. We produce timing chains, tensioners, guides and sprockets from high-carbon chromium alloy steel, in accordance with GB/T14212-2003 and JB/T10348-200 standards. Our Timing Chain Tensioner range covers 429 part numbers across universal and vehicle-specific applications.
Our tensioners maintain correct chain tension throughout the drive cycle, preventing tooth skip, chain slack and premature wear on the sprocket and guide. The range serves engine rebuilders, aftermarket distributors and OEM supply programmes for passenger cars, light commercial vehicles and selected industrial engines.
We organise tensioner supply by vehicle platform so that distributors and workshops can match parts to the engines they service. Each family below is supported by our own tooling and inspection records.
| Tensioner Family | Typical Engine Applications | Design Focus |
|---|---|---|
| Universal tensioner | Multi-platform service and repair | Broad fitment, hydraulic damping |
| Ford / Lincoln | 3.5, 4.0 and EcoBoost V6 | High-load chain take-up |
| Toyota / Lexus | K3-VE, 2ZR, 1GR families | Quiet running, stable oil feed |
| Nissan / Mazda / Mitsubishi / Suzuki | YD25, MZR, 4B11, K-series | Compact body, precise plunger travel |
| Volkswagen / Audi | EA888, 4.2L V8, TFSI | High-pressure hydraulic response |
| Benz / BMW | M271, N14, N20, N26 | Precision bore and spring rate |
| Chrysler / Dodge / Jeep | V6 and V8 truck engines | Heavy-duty damping, heat resistance |
| Chery and Chinese vehicles | Acteco and domestic engine families | Cost-effective volume supply |
Each tensioner is developed to match the chain pitch, guide profile and oil gallery position of the target engine. Where a platform uses a ratchet or mechanical backup, we replicate that function so the tensioner holds position during cold start and low oil pressure.
We machine tensioner bodies, plungers and check valves from alloy steel with controlled carbon and chromium content. Heat treatment is applied to wear surfaces, and hydraulic elements are tested for sealing and response before assembly.
For each part number we can supply the reference dimensions, material grade and inspection record that correspond to the drawing or sample approved by the customer.
We build tensioners to drawing or sample, which allows distributors and engine builders to specify the exact variant they need rather than adapting a generic part.
Oil-pressure-driven plunger with optional ratchet or spring backup for cold-start stability.
Flange, bolt pattern and oil feed port machined to the engine's original interface.
Phosphate, black oxide or anti-corrosion coating selected for the operating environment.
Neutral, branded or customer-specified cartons and labels for distribution.
Custom development follows the customer's drawing or a physical sample. We confirm material, hardness range, plunger travel and oil feed geometry before tooling is released.
Quality control runs through every production stage. Incoming steel is checked for chemical composition, and machined parts are inspected before heat treatment and after finishing. Our testing laboratory includes spectrometer, metallographic microscope, hardness tester, tension tester and dimensional measurement equipment.
Acceptance criteria are agreed with the customer before production. Where required, we provide inspection records and sample parts for fitment trials.
Correct installation protects the tensioner and the rest of the timing system. The tensioner should be fitted with a new chain, guide and sprocket where wear is present, and the oil circuit should be clean before the timing cover is closed.
Replacement intervals vary by engine and driving condition. Where the chain has stretched beyond the wear limit, we recommend replacing the complete timing set rather than the tensioner alone. Our Universal Timing Chain Kit 0121 and vehicle-specific kits provide matched components for this purpose.
Jingtong supplies the full timing chain system so that distributors can source matched components from one manufacturer. Tensioners are supported by chains, guides and sprockets for the same engine families.
Each kit is assembled from components produced to the same material and inspection standard as our individual tensioners.
To prepare a tensioner proposal we need the engine and vehicle details, the required quantity and the inspection or packaging requirements. The table below shows the project inputs we work from.
| Project Input | What We Need | How It Shapes the Proposal |
|---|---|---|
| Engine and vehicle | Make, model, engine code, year | Selects the correct tensioner family and part number |
| Reference sample or drawing | OEM number, drawing or physical sample | Confirms dimensions, material and hydraulic behaviour |
| Quantity and schedule | Annual volume, first order, delivery window | Sets production planning and packaging scope |
| Inspection requirements | Hardness, dimensions, leak test, records | Defines the acceptance plan and documentation |
| Packaging and branding | Carton design, labels, language | Prepares distribution-ready packaging |
We reply to working-day enquiries within 12 hours. Our production capacity exceeds 5,000,000 single parts annually, supported by more than 100 employees and a dedicated engineering team.
We are a direct manufacturer with two production facilities and our own international sales department. We produce and sell our timing chain tensioners ourselves, which gives us control over material, machining and inspection.
Yes. We develop and produce according to customer drawings or samples. Our engineering team confirms material grade, hardness range, plunger travel and oil feed geometry before tooling is released.
Our range covers universal tensioners and vehicle-specific parts for Ford, Jeep, Chrysler, Dodge, Toyota, Nissan, Mazda, Mitsubishi, Suzuki, Honda, Hyundai, Volkswagen, Audi, Benz, BMW, Fiat, Land Rover and Chery, among others.
We inspect after every process and perform 100% inspection on finished products. Our laboratory includes spectrometer, metallographic microscope, hardness tester, tension tester and dimensional measurement equipment. Production follows GB/T14212-2003 and JB/T10348-200 standards.
Our annual production capacity exceeds 5,000,000 single parts. Lead time depends on part number, quantity and tooling status, and is confirmed when we quote. We reply to enquiries within 12 hours on working days.
Yes. We supply timing chains, guides, sprockets and complete kits alongside our tensioner range, so distributors can source matched components for the same engine from one supplier.
